Basic elements
Technical illustrations
The illustrations in User Guides are used for technical matters only and whenever the product and its functionality needs to be explained appropriately, therefore we call them technical illustrations.
Hearing aids
Technical illustrations of Phonak hearing aids have a light grey background.
Devices
To explain how devices work a simple line drawing is ideal. Use the Phonak Green to indicate functions and directions.
People
To visualize people within technical illustration please use the basic set available on MAM. These files come as eps (vectored) and are ideal to be adapted by your creatives.
